Engine
Industrial diesel engine, Water Cooled, Equipped with Full Instrumentation and Safety Shut Down System
Optional Engines, Contact Strong Manufacturing for other engine options.
Mixer
Patented 27 cubic ft. Double-Drum Mixer, Hydraulically Operated via Mechanical Drive, Counter Rotating Ribbon Paddles, Rubber lined Equipped with Adjustable Packing Chambers and Outboard Bearings. Raised operator platform.
Material Pump
#80 Progressive Cavity Design Pump with adjustable speed drive, Chrome Rotor, Natural Rubber Stator, 8 cubic ft. Wet Material Holding Hopper with UHMW lining, Variable Output 0-30gpm @0 psi.
Options include 8 cubic ft. Material Blender, Material Hose Pressure Gauge
Water System
1 ½” water meter with manual discharge valve, Automatic Shut-off Fill Valve
Options include, Hydraulic Powered Water Pump, Digital Water Meter
Hydraulic System
Variable Displacement Pressure Compensated Piston Pump with Fixed Displacement Gear Pump, Hydraulic Oil Cooler, 45 Gallon Hydraulic Oil Reservoir
Frame
Made of Tubular Steel, Tandem Axle, 14” Tires, Torsion Suspension, Electric Brakes, Running Lights, Ball or Pintle Hitch. Optional: Hose Reel
Dimensions
Length: 14’8” Width: 6’3” Height: 8’6” Weight: 4900lbs.
