Cellular Concrete Pump
Engine
Industrial Diesel Water Cooled Engine: Equipped with Full Instrumentation and Safety Shut Down System, Four Speed Transmission.
Optional Engines, Contact Strong Manufacturing for other engine options.
Material Pump
Strong #80 progressive cavity pump. 12 cubic foot cellular concrete holding hopper. Adjustable speed drive, 50 GPM maximum discharge rate.
Air Compressor
Hydraulic Powered: 40CFM @ 200 PSI
Water Holding Tank
110-Gal Capacity
Auto-Foam Generator
Panel with digital flow meters for both the liquid and air components
12 GPM water-driven, adjustable, concentrate metering pump
Nozzles for various foam output production
120V electric-driven solution booster pump
14-Gal foam solution surge tank
AIR REQUIREMENTS: Minimum-5CFM @60PSI Maximum-30CFM @150PSI
WATER REQUIREMENT: Minimum- 1GPM @60PSI Maximum-12GPM @100PSI
